Potential divider circuits
I can calculate p.d. across one of two components in a series circuit with a battery.
Potential divider circuits
I can calculate p.d. across one of two components in a series circuit with a battery.
Lesson details
Key learning points
- The p.d. across a component in an electric circuit measures the size of push that is moving current through it.
- The p.d. across each component in a series circuit adds up to the p.d. across the battery.
- The current is the same through every component in a series circuit.
- The larger the total resistance of a series circuit, the smaller the current through it.
- In a series circuit, the share of p.d. across each component is proportional to its resistance.
Keywords
Series circuit - an electrical circuit with a single loop
Potential difference (p.d.) - a measure of the push an electric field gives to charges
Resistance - a property of a material that opposes the flow of current
Potential divider - a series circuit that divides the p.d. across a power supply into two or more smaller voltages
Common misconception
A battery pushes a constant current around a circuit.
Provide opportunity for pupils to measure p.d. across a power supply when the resistance of a circuit it is connected to is altered.
Equipment
variable resistor, lamp, power supply, two voltmeters, electrical leads
Content guidance
- Risk assessment required - equipment
Supervision
Adult supervision required
Licence
This content is © Oak National Academy Limited (2024), licensed on Open Government Licence version 3.0 except where otherwise stated. See Oak's terms & conditions (Collection 2).
Lesson video
Loading...
Starter quiz
6 Questions
Exit quiz
6 Questions
